There are many ways to build e-commerce applications. This article will look at how to build an e-commerce application using React, MongoDB, Strapi, and Socket.io. We will use React for the frontend, MongoDB for the database, Strapi as our Content Management System (CMS, also serves as our backend tool), and Socket.io for real-time bi-directional communication between the client and the server. # Outline - Introduction - Brief Overview of Strapi - Brief Overview of Socket.io - Building the E-commerce application - Setting up MongoDB - Setting up a Strapi project - Building the collections - Building the frontend with React - Integrating Sockets - Integrating Socket on the Backend - Integrating Socket on the Frontend - Adding products in real-time - Adding reviews in real-time - Conclusion. # Goals In this article, you will learn how Socket.io works and how it is integrated into Strapi and frontend environments as well as how Strapi makes backend development seamless. # Prerequisites To get the best of this tutorial, you need prior knowledge of the following: 1. Basic knowledge of JavaScript 2. Basic knowledge of ReactJS 3. Basic understanding of Strapi - [get started here](https://strapi.io/documentation/developer-docs/latest/getting-started/introduction.html). Also, download and install [Node.js](https://nodejs.org/en/) if you haven't already. # Brief overview of Strapi? In a concise form, Strapi is a headless CMS. As the term headless implies, the CMS has no head. It's decoupled. If that doesn't make sense yet, think about WordPress. When using WordPress, they manage your frontend, backend, data, and, possibly your hosting too. With headless CMSs like Strapi, while managing your content, you choose where your data stays, decide where your application is hosted, and make up your frontend yourself—basically giving you more control over how your application is structured. Strapi allows you to develop and manage your content using APIs (REST and GraphQL). Here's more information: [Strapi Developer Documentation](https://strapi.io/documentation/developer-docs/latest/getting-started/introduction.html). # Brief Overview of Socket.io [Websockets](https://developer.mozilla.org/en-US/docs/Web/API/WebSockets_API) in web development is a technology that allows bi-directional and real-time communication between a client and a server. Socket.io is a library that makes working with Websockets easier on browsers and Node.js servers. The traditional way of building websites involves the client requesting resources from the server and responding to the client. After that response, the server cannot send any other response. It has to wait until there's a request. Websockets make things different. With them, servers and clients work together using events. The client emits an event, the server listens for that event and acts accordingly, and vice versa. This way, even when the client doesn't request data, the server can emit an event (at any time), and the client's listeners will handle the event. ## Building the E-commerce application The e-commerce application we'll be building has two collections—products and reviews. Each Product can have reviews. We'll show how to achieve this seamlessly using the above tools. The work of Socket.io here is to improve the interaction in the web application. Here are few things we'll see with Socket.io: - notify other users when a product is added - add a product in real-time to the products list - add a product review in real-time Let's get started building. ### Setting up MongoDB Before starting with our project, we want to ensure our database is ready. Follow the instructions in this detailed article: [MongoDB - Strapi Developer Documentation](https://strapi.io/documentation/developer-docs/latest/setup-deployment-guides/configurations/databases/mongodb.html#_2-install-strapi-locally-with-mongodb). ### Setting up a Strapi project Setting up a Strapi project is pretty straightforward. Just like `create-react-app`, `@vue/cli`, and the rest of them, Strapi has [create-strapi-app](https://strapi.io/documentation/developer-docs/latest/setup-deployment-guides/installation/cli.html#creating-a-strapi-project). Run the following command: ```bash mkdir ecommerce npx create-strapi-app backend ``` First, we create a new directory for our frontend and backend application. Then using [npx](https://www.npmjs.com/package/npx) (used for executing npm libraries without installing them, you can choose to install the `create-strapi-app` globally and use directly), we set up the backend. While setting up, you'll be asked some questions. Here's one: ![Screenshot showing the installation type question](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630997406784_image.png) For this tutorial, we want to use MongoDB. Using Quickstart, the default database (SQLite) will be used. So, select custom. And the next question: ![Screenshot showing some questions from the strapi CLI](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630997506628_image.png) Templates are not starters—they are not apps. They are just already made with Strapi configurations, components, and plugins. Here's a list of them: [Strapi Templates](https://github.com/strapi/awesome-strapi#Templates) For this tutorial, we won't be using them. To enter `n` and press enter. Next question: ![Screenshot showing the database client question](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630997925030_image.png) You know what to select 😅 With your mongo background service running, enter `eCommerce` as the database name: ![](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630997969185_image.png) For the remaining inputs, use the default, with the username and password empty. ![Screenshot showing some questions and default answers](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630998040227_image.png) ![Screenshot showing some questions and default answers](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631190814973_image.png) Now the backend code (built with Strapi) exists in the backend directory. ## Building the collections We will need two collection types for this tutorial. A Product Collection and the Review Collection will have a relationship with the Product. First, ensure you're in the backend directory: ```bash cd backend ``` Then, run `yarn develop`. The admin UI will be built with the development configuration, and your browser will open the page at `http://localhost:1337/admin/auth/register-admin`: ![Strapi admin registration form](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631252971982_image.png) You have to register as an administrator, so fill the form (take note of your credentials) and click on "Let's Start." And then you have this: ![Strapi admin dashboard panel](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253057851_image.png) So, for our first Content-Type, click on `Create your first Content-Type`: ![Collection Type Dialog](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1630999719105_image.png) On the Display name, enter `Product`, then click Continue. Next, you're to enter some fields: ![Collection fields dialog](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253125039_image.png) Select Text: ![Collection fields dialog](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253151869_image.png) In the Name field, enter `name`, which will be the name of the **Product**. Then, click on **Advanced settings**: ![Collection field dialog for the name field](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253183339_image.png) Select the `Required field` checkbox. With this selected, during creation (through the API), there would be a validation error if this field is not provided. You can also set a maximum or minimum length if you want. Then click `Add another field`. In this second field, select Media, and use `images` as the name. In the Advanced settings: ![Collection field dialog for the images field](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253281249_image.png) Change the `allowed types of media` to Images only and check the Required checkbox. Click `Add another field` for the last field. Select text, and enter `description` as the name. ![Collection field dialog for the description field](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253308890_image.png) Also, select `Long text`. Go to the advanced settings again and make it required. And then click `Finish`. Then, click `Save` at the top to add that collection. The server would restart with the new collection saved. Then we have to repeat the same process for the Review collection. Click on `Content-Types Builder` from the left-side navigation, and click on `Create new collection type` in the `Collection Types` section. The display name here would be `Review`, and the fields here are: - `reviewer_name`, required, of short text - `review`, required, of long text And the last field is of the `Relation` type. The field name on the Review collection is `product`, and the field name on the Product collection is `reviews` with a Many to One relationship: ![Collection field dialog for the Review relation field](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253666062_image.png) This means one Product can have many reviews. Then click Finish and Save. Our collections are ready. Under the `Collection Types` in the navigation, we can select a collection and add data directly on the UI. Go to the Product collection, and add two products of your choice. Here's the information I'm using: ![Dashboard for adding a product entry](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631256385033_image.png) Then click Save and Publish. Repeat the same for another entry of your choice. Go to the `Review` collection and add three reviews—two for one Product and one for the other. When adding reviews, you can select the `Product` you're adding a review for because Reviews have a relationship with Products: ![UI for adding a Relation entry](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631253984332_image.png) Now let's build our frontend and call the available APIs. ## Building the Frontend with React We'll be building the Frontend app with React. You can use any other framework as this serves as the UI and then calling APIs. In the `eCommerce` directory, run the following in the terminal. ```bash npx create-react-app client ``` Then run the following: ``` cd client npm run start ``` We'll have three pages. First page is to view all products, the second page is to view the detail of a particular product (with the reviews), and the third one to add a product. We need a `react-router` set up for this. Do the following: ```bash npm install react-router-dom ``` Open the `App.js` file and replace the code there with this: ``` import React from 'react' import { BrowserRouter as Router, Switch, Route } from 'react-router-dom' import Home from './components/Home' export default function App() { return ( ) } ``` Create a `components` directory under `src` and Add the `Home.js` file: ``` export default function Home() { return

Homepage

} ``` Now, when you go to http://localhost:3000, you should see the Homepage heading. Now, let's fetch the products from the backend. To call the APIs on the backend, a user would need to be authenticated. Since that's not our focus, we can make some request methods public. To do this, go back to your `backend` directory and run `yarn develop`, and open the admin dashboard at http://localhost:1337/admin. Then log in with your details. On the left navigation, go to Settings. Under `USERS & PERMISSIONS PLUGIN`, click on Roles: ![Setting Roles in the Strapi Admin dashboard](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631255642384_image.png) Then click on Public. Scroll to Permissions and select all: ![Setting permissions in the Strapi Admin dashboard](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631255978825_image.png) Then click Save. Note that this isn't ideal for a public app. Users need to be authenticated. Install Axios on our frontend for calling the API: ```bash npm install axios ``` Update `Home.js` to the following: ``` import axios from 'axios' import { useEffect, useState } from 'react' import './Home.css' import { Link } from 'react-router-dom' export default function Home() { const [products, setProducts] = useState([]) useEffect(() => { axios({ method: 'get', url: 'http://localhost:1337/products', }).then((res) => { setProducts(res.data) }) }, []) return (

Products

{products.map((product) => (

{product.name}

{product.description}

))}

) } ``` The images field is an array because when setting up the collection, we accepted multiple media. And the `URL` field on each image is in the form of `/uploads/…` which means we have to append that to the backend's server's URL to get the complete URL. And also, add a `Home.css` file in the same directory as `Home.js`, with the following code: ``` .products-container { display: grid; grid-template-columns: repeat(3, 1fr); grid-gap: 20px; } .product { text-decoration: none; border: 1px solid rgb(236, 235, 235); } .product-image img { height: 400px; color: rgb(229, 224, 224); } .product-details { padding: 15px; } .product-name { margin: 10px 0 0; color: rgb(103, 103, 103); } .product-desc { margin: 10px 0 0; color: rgb(187, 187, 187); } ``` Also add the `.container` class in the `index.css` file as so: ``` .container { padding: 40px; max-width: 1000px; margin: 0 auto; } * { box-sizing: border-box; } ``` Now, I have this: ![Screenshot of the built homepage](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631256950372_image.png) On clicking each Product, I expect to see a dedicated page for that Product with the reviews. So, create a `ProductDetail` component at the components directory: ``` import axios from 'axios' import { useEffect, useState } from 'react' import { useParams } from 'react-router-dom' import './ProductDetail.css' export default function ProductDetail() { const { product_id } = useParams() const [product, setProduct] = useState(null) useEffect(() => { axios({ method: 'get', url: `http://localhost:1337/products/${product_id}`, }).then((res) => { setProduct(res.data) }) }, []) return (

{!product ? ( Loading... ) : (

{product.name}

{product.description}

Reviews ({product.reviews.length})

{product.reviews.map((review) => (

{review.reviewer_name}

{review.review}

))}

)}

) } ``` And a `ProductDetail.css` file at the same directory: ``` .product-img-container { height: 500px; overflow: hidden; } .product-img-container img { object-fit: cover; width: 100%; height: 100%; } .product-reviews { padding-top: 20px; border-top: 1px solid #ccc; } .product-review { background-color: #eeecec; padding: 15px; } ``` Also, go back to `App.js` and update the second `Route` component to this: ... ... Now when you click on a product, you get this: ![Screenshot of a product detail page](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631257970168_image.png) ## Integrating Sockets As our application is currently, there is communication between the frontend and the backend. But we want this communication to be bi-directional and in real-time so let's integrate sockets. ### Integrating Socket on the Backend ```bash npm install socket.io ``` The [config/functions/bootstrap.js](https://strapi.io/documentation/developer-docs/latest/setup-deployment-guides/configurations.html#functions) file is the starting point that Strapi uses when your development starts. So it's in here we integrate Sockets—our listeners and emitters and so on. Replace the bootstrap file with the following: ``` module.exports = () => { const io = require("socket.io")(strapi.server, { cors: { origin: "http://localhost:3000", methods: ["GET", "POST"], }, }); io.on("connection", function (socket) { // send message on user connection socket.emit("hello", JSON.stringify({ message: "Welcome to my website" })); }); }; ``` We've configured the `socket.io` library to use Strapi's server, with some `cors` permissions. When any client connects to the server, the `connection` event is automatically emitted, and the server can listen to it and do whatever it wants. In this example, on `connection`, the server emits the `hello` event, and the client can listen to it and display the message. ## Integrating Socket on the Frontend Install the socket.io client library: ```bash npm i socket.io-client react-toastify ``` The [react-toastify](https://www.npmjs.com/package/react-toastify) library is used for adding notifications to our app. In the `App.js` file, add the following: ``` // other imports import { ToastContainer } from 'react-toastify' import 'react-toastify/dist/ReactToastify.css' ... ... ``` Create a new directory called `config`, and in it, create a `socket.js` file with the following code: ``` import { io } from 'socket.io-client' export const socket = io('http://localhost:1337') ``` And back in the `Home.js` file, update to the following: ``` // other imports import { socket } from '../config/socket' import { toast } from 'react-toastify' socket.on('hello', (res) => { toast.success(res.message) }) export default ... ``` Now, when you load the products page, you get: ![Screenshot of the homepage with a notification saying welcome](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631259749208_image.png) There is indeed a socket connection. The next thing we want to do is emit an event when a product is added. ## Adding Products in Real-time Let’s create the component--`AddProduct.js`: ``` import { useState } from 'react' import { toast } from 'react-toastify' import { socket } from '../config/socket' import './AddProduct.css' export default function AddProduct() { const [name, setName] = useState(null) const [description, setDescription] = useState(null) const [processing, setProcessing] = useState(false) const formSubmit = (e) => { e.preventDefault() setProcessing(true) socket.emit('addProduct', { name, description }, (product) => { setProcessing(false) toast.success('Product added successfully!') setTimeout(() => { window.location.href = `/${product.id}` }, 1000) }) } return (

Add Product

) } ``` In the form submit handler, we emit an event named `addProduct` with an object of the Product's properties. Notice we aren't using Axios for the POST request? Because sockets do that already. We also add a callback function with the argument `product`, which will be passed from the backend when created. Then we navigate to that Product's detail page after 1 second. And the `AddProduct.css file`: ``` .add-product h1 { text-align: center; } .add-product form { max-width: 600px; margin: 0 auto; border: 1px solid #ccc; padding: 15px; } .input-group { width: 100%; margin-bottom: 20px; } .input-group label { display: block; margin-bottom: 5px; } .input-group input { padding: 20px; width: 100%; } .add-product form button { width: 100%; padding: 20px; border: none; background: none; background-color: rgb(193, 251, 193); cursor: pointer; } ``` After adding the AddProduct component in `App.js` , `/add-product/` gives us: ![Screenshot of the add product page](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631271104313_image.png) We'll leave adding the image for the Product on the Strapi admin dashboard. In the `img` `src` in the homepage and product detail page, change it to: ```

``` This way, we check if there's an image, and if there isn't, we use a default image. In the public directory at the root, add an `empty-box.SVG` file and paste the following: ``` ``` Also, go back to `Home.js` and add listen to the product added event: ``` ... socket.on('hello', (res) => { toast.success(res.message) }) socket.on('newProductAdded', (res) => { toast.info('A new product has been added') setProducts((products) => [res.product, ...products]) }) ... ``` When the backend emits this event, we can listen to it on the homepage (opened in another tab or window), show the toaster, and add the products to the existing products array. Now for the backend work. In the `config` directory, create a `utils` directory, and in it, create a `product-database.js` file. In that file, paste the following: ``` async function createProduct({ name, description }) { try { const product = await strapi.services.product.create({ name, description, }); return product; } catch (err) { console.log({ err }); return "Product cannot be created. Try again"; } } module.exports = { createProduct, }; ``` Here, we're using the Strapi product service to create the Product, which would add that to the database. Now, go back to the `bootstrap.js` file and after the `hello` emitted event, add the following: ``` ... socket.on("addProduct", async ({ name, description }, callback) => { try { const product = await createProduct({ name, description, }); if (product) { callback(product); socket.broadcast.emit("newProductAdded", { product }); } } catch (err) { console.log({ err }); callback({ type: "error", message: err }); console.log("Error occured. Please try again"); } }); ... ``` We listen to the `addProduct` event, add the Product to the database, pass the Product as the argument to the client's callback, and emit the event `newProductAdded` with the Product. Notice we aren't using a `socket.emit` but `socket.broadcast.emit instead` since `socket.emit` emits the event to the client that emitted the `addProduct` event. We don't want this because the client is currently on the add product page, which means the homepage will never listen to the event. But with `socket.broadcast.emit`, we're emitting the event to every other connected event, except the client that sent the `addProduct` event. Now, let's test what we have. I'm using two windows for this. Here are the two pages: ![Screenshot of two windows: one for the home page and the other for the add product page](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631271856592_image.png) After adding a product, then this: ![Screenshot of two windows: one showing a new product was added and the other is the add product page after submission](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631271918675_image.png) Notice in the homepage, the Product is added, and the toaster notifies the user? This is very similar to Twitter telling you, "New tweets available." ## Adding reviews in real-time The same thing can be done with reviews. The basic idea is to have a `ProductReviews` component that has a form where users can enter reviews. On the same Product Reviews component, there'd be a listener for the `newReviewAdded` event. And we can broadcast emit to other connected clients, letting them know of the newly added review. ![Screenshot of two windows: one showing the reviews section after submission and the other showing a new review was added](https://paper-attachments.dropbox.com/s_74B6A00D6E55C4AFBA28873EF328A1C0FF93B942E332CF965C772AB3C8A8E7CE_1631274166596_image.png) In the screenshot above, the upper window was the client that sent the review. In contrast, the window below is just another client that is notified of an added review. Here’s the source code for the tutorial: https://github.com/dillionmegida/ecommerce-socket-io-strapi ## Do we still need Axios? We don't. For getting the products initially, we can emit an event from the backend called `loadedProducts` and listen to that event on the frontend to fetch and display the products. ## Conclusion In this article, we've seen how to create a full-stack e-commerce application with Strapi managing the backend and React for the frontend. We also saw how to integrate web sockets to improve the communication and interaction between the client and the server. For further reading, check out: [Real-time Chat Forum using Strapi, Socket.io, React, and MongoDB](https://strapi.io/blog/how-to-build-a-real-time-chat-forum-using-strapi-socket-io-react-and-mongo-db)
