Build a blog with Angular, Strapi and Apollo

This tutorial is outdated since it is using Strapi v3.

Introduction

This month, we published two tutorials on how to create a blog with Nuxt.js and how to create a blog with Next.js with Strapi. But as the saying goes, good things come in threes!

So we decided to also create a tutorial for Angular developers on how to create a blog using Strapi and Apollo, and we hope you'll enjoy using it.

If you are familiar with our blog you must have seen that we've released a series of tutorials on how to make blogs using Strapi with a lot of frontend frameworks: Gatsby Old, Gatsby new, React, Next.js, Vue or Nuxt

Angular is a TypeScript-based open-source web application framework led by the Angular Team at Google and by a community of individuals and corporations. Angular is a complete rewrite from the same team that built AngularJS.

Goal

The goal here is to be able to create a blog website using Strapi as the backend, Angular for the frontend, and Apollo for requesting the Strapi API with GraphQL.

The source code is available on GitHub.

Prerequisites

To follow this tutorial, you'll need to have Strapi and Angular installed on your computer, but don't worry, we are going to install these together!

This tutorial uses Strapi v3.0.0-beta.17.8.

You need to have node v.12 installed and that's all.

Setup

Create a blog-strapi folder and get inside!

mkdir blog-strapi && cd blog-strapi

Back-end setup

So that's the easy part. Since the beta.9, we have an awesome package create strapi-app that allows you to create a Strapi project in seconds without installing Strapi globally so let's try it out.

Note: for this tutorial, we will use yarn as your package manager.

yarn create strapi-app backend --quickstart --no-run.

This single command line will create all you need for your back-end. Make sure to add the --no-run flag as it will prevent your app from automatically starting the server because SPOILER ALERT: we need to install some awesome Strapi plugins.

Now that you know that we need to install some plugins to enhance your app, let's install one of our most popular. The graphql plugin:

yarn strapi install graphql

Once the installation is completed, you can finally start your Strapi server strapi dev and create your first Administrator.

Don't forget that Strapi is running on http://localhost:1337.

Nice! Now that Strapi is ready, we are going to create your Angular application.

Front-end setup

Well, the easiest part has been completed, let's get our hands dirty developing our blog!

Angular setup

• Install the Angular CLI by running the following command:

  npm install -g @angular/cli

• Create an Angular frontend project, and accept to add Angular routing:

  ng new frontend

Now your project is all set, you can dive in it and run the server:

1cd frontend
2ng serve

As you might want people to read your blog or to make it "cute & pretty" we will use a popular CSS framework for styling: UiKit and also Apollo to query Strapi with GraphQL:

Dependencies setup

Make sure you are in the frontend folder before running the following commands:

Apollo setup

• Install apollo-angular by running the following command:

  ng add apollo-angular

• Go in src/app/graphql.modules.ts and modify the uri const:

  const uri = 'http://localhost:1337/graphql';

This way, Apollo will call this address, which is the GraphQL route of your Strapi API.

UIkit setup

UIkit is a lightweight and modular front-end framework for developing fast and powerful web interfaces.

• Install UIkit by running the following command:

  yarn add uikit

• Open your angular.json file and add the following code in the first scripts array. It should look like this:

1"scripts": [
2  "node_modules/jquery/dist/jquery.min.js",
3  "node_modules/uikit/dist/js/uikit.min.js",
4  "node_modules/uikit/dist/js/uikit-icons.min.js"
5]

• Open your src/style.css and paste the following code:

1/* You can add global styles to this file, and also import other style files */
2@import "../node_modules/uikit/dist/css/uikit.min.css";
3@import "../node_modules/uikit/dist/css/uikit.css";
4@import "../node_modules/uikit/dist/css/uikit-core.css";
5@import url("https://fonts.googleapis.com/css?family=Staatliches");
6
7a {
8  text-decoration: none;
9}
10
11h1 {
12  font-family: Staatliches;
13  font-size: 120px;
14}
15
16#category {
17  font-family: Staatliches;
18  font-weight: 500;
19}
20
21#title {
22  letter-spacing: 0.4px;
23  font-size: 22px;
24  font-size: 1.375rem;
25  line-height: 1.13636;
26}
27
28#banner {
29  margin: 20px;
30  height: 800px;
31}
32
33#editor {
34  font-size: 16px;
35  font-size: 1rem;
36  line-height: 1.75;
37}
38
39.uk-navbar-container {
40  background: #fff !important;
41  font-family: Staatliches;
42}
43
44img:hover {
45  opacity: 1;
46  transition: opacity 0.25s cubic-bezier(0.39, 0.575, 0.565, 1);
47}

Note: You're importing UIkit style and a beautiful font that you'll use for this tutorial.

Designing the data structure

Finally! We are now going to create the data structure of our article by creating an Article content type.

• Dive in your Strapi admin panel and click on the Content Type Builder link in the sidebar.

• Click on Create new content-type and call it article.

Now you'll be asked to create all the fields for your content-type:

• Create the following ones:
  • title with type Text (required)
  • content with type Rich Text (required)
  • image with type Media (Single image) and (required)
  • published_at with type date (required)

Press Save! Here you go, your first content type has been created. Now you may want to create your first article, but we have one thing to do before that: Grant access to the article content type.

• Click on the Settings then Roles & Permission and click on the public role.
• Check the article find and findone routes and save.

Awesome! You should be ready to create your first article right now and fetch it on the GraphQL Playground.

• Now, create your first article !

Here's an example:

Great! Now you may want to reach the moment when you can actually fetch your articles through the API!

• Go to http://localhost:1337/articles.

Isn't that cool! You can also play with the GraphQL Playground.

Create categories

You may want to assign a category to your article (news, trends, opinion). You are going to do this by creating another content type in Strapi.

• Create a category content type with the following field
  • name with type Text

Press save!

• Create a new field in the Article content type which is a Relation Category has many Articles like below:

• Click on the Settings then Roles & Permission and click on the public role. And check the category find and findone routes and save.

Now you'll be able to select a category for your article in the right sidebox.

Now that we are good with Strapi let's work on the frontend part!

Nav component

Let's create our first component and see what happens.

• Create a nav component by running the following command:

  ng generate c nav --skip-import

Four files have been created, but we'll only work with the .html and .ts files. In fact your .html file is the view of your component and your .ts file defines what your component will basically do.

I'm going to explain this component in detail, but it will be the same procedures for the other ones.

First of all, you want to fetch categories you've created with Strapi. To do so, you'll create a graphql request and use it in your component.

• Create a app/apollo/queries/category directory
• Create a app/apollo/queries/category/categories.js file and paste the following code inside:

1import gql from "graphql-tag";
2
3const CATEGORIES_QUERY = gql`
4  query Categories {
5    categories {
6      id
7      name
8    }
9  }
10`;
11
12export default CATEGORIES_QUERY;

Here, you are simply fetching the id and the name of every category.

Now lets import this query and the necessary packages:

• Add this to the top of your nav/nav.component.ts file:

1import { Apollo } from "apollo-angular";
2import gql from "graphql-tag";
3import CATEGORIES_QUERY from "../apollo/queries/category/categories";
4import { Subscription } from "rxjs";

• Replace the export by the following one:

1export class NavComponent implements OnInit {
2  data: any = {};
3  loading = true;
4  errors: any;
5
6  private queryCategories: Subscription;
7
8  constructor(private apollo: Apollo) {}
9
10  ngOnInit() {
11    this.queryCategories = this.apollo
12      .watchQuery({
13        query: CATEGORIES_QUERY
14      })
15      .valueChanges.subscribe(result => {
16        this.data = result.data;
17        this.loading = result.loading;
18        this.errors = result.errors;
19      });
20  }
21  ngOnDestroy() {
22    this.queryCategories.unsubscribe();
23  }
24}

What you're doing here is fetching all your categories with Apollo on the component initialization using the query you made. Let's write our Navbar!

• Open nav/nav.component.html and paste the following code:

1<nav class="uk-navbar-container" uk-navbar>
2  <div class="uk-navbar-left">
3    <ul class="uk-navbar-nav">
4      <li class="uk-active"><a href="#">Strapi blog</a></li>
5    </ul>
6  </div>
7
8  <div class="uk-navbar-right">
9    <ul *ngIf="data" class="uk-navbar-nav">
10      <li *ngFor="let category of data.categories" class="uk-active">
11        <a
12          routerLink="/category/{{ category.id }}"
13          routerLinkActive="active"
14          class="uk-link-reset"
15        >
16          {{ category.name }}
17        </a>
18      </li>
19    </ul>
20  </div>
21</nav>

Inside the view, we can access our categories with data.categories. We can then iterate on it in order to display them all *ngFor="let category of data.categories".

Perfect! Now we need to two things!

• Open your app.modules.ts file and import your newly created nav component by importing it and adding it to the declarations array like this:

1...
2import { NavComponent } from "./nav/nav.component";
3...
4
5declarations: [
6  AppComponent,
7  NavComponent
8],
9...

• Open your app.component.html file and declare your nav component by pasting the following code:

1<app-nav></app-nav>
2
3<router-outlet></router-outlet>

This way, your nav component will always be displayed on your application

Note The current code is not suited to display a lot of categories as you may encounter a UI issue. Since this blog post is supposed to be short, I will let you improve the code to maybe add a lazy load or something.

For now, the links are not working, you'll work on it later on the tutorial ;)

Note It will now be the same exact logic for every other component:

• Generate the component
• Create the GraphQL query
• Fetch your data in your .ts file
• Create the view in your .html file
• Register your component in app.module.ts
• Some routing :)

Articles component

This component will display all your articles and will be displayed on the main page.

• Create an articles component by running the following command:

  ng generate c articles --skip-import

• Create a app/apollo/queries/article directory.

• Create a app/apollo/queries/article/articles.js file and paste the following code inside:

1import gql from "graphql-tag";
2
3const ARTICLES_QUERY = gql`
4  query Articles {
5    articles {
6      id
7      title
8      category {
9        id
10        name
11      }
12      image {
13        url
14      }
15    }
16  }
17`;
18
19export default ARTICLES_QUERY;

• Open your articles/articles.component.ts file and paste the following code:

1import { Component, OnInit } from "@angular/core";
2import { Apollo } from "apollo-angular";
3import gql from "graphql-tag";
4import ARTICLES_QUERY from "../apollo/queries/article/articles";
5import { Subscription } from "rxjs";
6
7@Component({
8  selector: "app-articles",
9  templateUrl: "./articles.component.html",
10  styleUrls: ["./articles.component.css"]
11})
12export class ArticlesComponent implements OnInit {
13  data: any = {};
14  loading = true;
15  errors: any;
16  leftArticlesCount: any;
17  leftArticles: any[];
18  rightArticles: any[];
19
20  private queryArticles: Subscription;
21
22  constructor(private apollo: Apollo) {}
23
24  ngOnInit() {
25    this.queryArticles = this.apollo
26      .watchQuery({
27        query: ARTICLES_QUERY
28      })
29      .valueChanges.subscribe(result => {
30        this.data = result.data;
31        this.leftArticlesCount = Math.ceil(this.data.articles.length / 5);
32        this.leftArticles = this.data.articles.slice(0, this.leftArticlesCount);
33        this.rightArticles = this.data.articles.slice(
34          this.leftArticlesCount,
35          this.data.articles.length
36        );
37        this.loading = result.loading;
38        this.errors = result.errors;
39      });
40  }
41
42  ngOnDestroy() {
43    this.queryArticles.unsubscribe();
44  }
45}

What you are doing here is fetching your articles thanks to the query you wrote, then you separate them in two arrays. In fact, leftArticles will contain articles that will be displayed on the left side and rightArticles on the right side.

• Open your articles/articles.component.html and paste the following code:

1<div class="uk-section">
2  <div class="uk-container uk-container-large">
3    <h1>Strapi blog</h1>
4
5    <div class="uk-child-width-1-2" uk-grid>
6      <div>
7        <a
8          routerLink="/article/{{ article.id }}"
9          routerLinkActive="active"
10          *ngFor="let article of leftArticles"
11          class="uk-link-reset"
12        >
13          <div class="uk-card uk-card-muted">
14            <div *ngIf="article.image" class="uk-card-media-top">
15              <img
16                src="http://localhost:1337{{ article.image.url }}"
17                alt=""
18                height="100"
19              />
20            </div>
21            <div class="uk-card-body">
22              <p
23                id="category"
24                *ngIf="article.category"
25                class="uk-text-uppercase"
26              >
27                {{ article.category.name }}
28              </p>
29              <p id="title" class="uk-text-large">{{ article.title }}</p>
30            </div>
31          </div>
32        </a>
33      </div>
34      <div>
35        <div class="uk-child-width-1-2@m uk-grid-match" uk-grid>
36          <a
37            routerLink="/article/{{ article.id }}"
38            routerLinkActive="active"
39            *ngFor="let article of rightArticles"
40            class="uk-link-reset"
41          >
42            <div class="uk-card uk-card-muted">
43              <div *ngIf="article.image" class="uk-card-media-top">
44                <img
45                  src="http://localhost:1337{{ article.image.url }}"
46                  alt=""
47                  height="100"
48                />
49              </div>
50              <div class="uk-card-body">
51                <p
52                  id="category"
53                  *ngIf="article.category"
54                  class="uk-text-uppercase"
55                >
56                  {{ article.category.name }}
57                </p>
58                <p id="title" class="uk-text-large">{{ article.title }}</p>
59              </div>
60            </div>
61          </a>
62        </div>
63      </div>
64    </div>
65  </div>
66</div>

• Open your app.modules.ts file, import your component and add it to the declarations array like this:

1...
2import { ArticlesComponent } from "./articles/articles.component";
3...
4
5declarations: [
6  AppComponent,
7  ArticlesComponent,
8  NavComponent,
9],

It's time to use the router from angular. You want to display this ArticlesComponent on your main page

• Import RouterModule, Routes from Angular and define the following appRoutes:

1import { RouterModule, Routes } from "@angular/router";
2...
3
4const appRoutes: Routes = [
5  { path: "", component: ArticlesComponent }
6];

• And then add your RouterModule to your imports array:

1...
2imports: [
3  RouterModule.forRoot(appRoutes, { enableTracing: true }),
4  BrowserModule,
5  AppRoutingModule,
6  GraphQLModule,
7  HttpClientModule
8],
9...

Great! You can now list every article on your main page.

Nothing happens if you click on any article, let's change that!

Article Component

• Create an article component by running the following command:

  ng generate c article --skip-import

• Create a app/apollo/queries/article/article.js file and paste the following code inside:

1import gql from "graphql-tag";
2
3const ARTICLE_QUERY = gql`
4  query Articles($id: ID!) {
5    article(id: $id) {
6      id
7      title
8      content
9      image {
10        url
11      }
12      category {
13        id
14        name
15      }
16      published_at
17    }
18  }
19`;
20
21export default ARTICLE_QUERY;

• Open your article/article.component.ts and paste the following code:

1import { Component, OnInit } from "@angular/core";
2import { Apollo } from "apollo-angular";
3import gql from "graphql-tag";
4import ARTICLE_QUERY from "../apollo/queries/article/article";
5import { ActivatedRoute } from "@angular/router";
6import { Subscription } from "rxjs";
7
8@Component({
9  selector: "app-article",
10  templateUrl: "./article.component.html",
11  styleUrls: ["./article.component.css"]
12})
13export class ArticleComponent implements OnInit {
14  data: any = {};
15  loading = true;
16  errors: any;
17
18  private queryArticle: Subscription;
19
20  constructor(private apollo: Apollo, private route: ActivatedRoute) {}
21
22  ngOnInit() {
23    this.queryArticle = this.apollo
24      .watchQuery({
25        query: ARTICLE_QUERY,
26        variables: {
27          id: this.route.snapshot.paramMap.get("id")
28        }
29      })
30      .valueChanges.subscribe(result => {
31        this.data = result.data;
32        this.loading = result.loading;
33        this.errors = result.errors;
34      });
35  }
36  ngOnDestroy() {
37    this.queryArticle.unsubscribe();
38  }
39}

The content of our articles are not in Markdown, you'll need to install a dependency to display the content of your articles in Markdown.

• Install ngx-markdown by running the following command:

  yarn add ngx-markdown

• Open your app.modules.ts, import add the MarkdownModule to your imports array:

1...
2import { MarkdownModule } from "ngx-markdown";
3...
4
5imports: [
6  MarkdownModule.forRoot(),
7  RouterModule.forRoot(appRoutes, { enableTracing: true }),
8  BrowserModule,
9  AppRoutingModule,
10  GraphQLModule,
11  HttpClientModule
12],
13...

Awesome! Let's move on to the next step.

• Open your article/article.component.html and paste the following code:

1<div
2  id="banner"
3  class="uk-height-small uk-flex uk-flex-center uk-flex-middle uk-background-cover uk-light uk-padding"
4  [style.background-image]="
5    'url(http://localhost:1337' + data.article.image.url + ')'
6  "
7  uk-img
8>
9  <h1>{{ data.article.title }}</h1>
10</div>
11
12<div class="uk-section">
13  <div class="uk-container uk-container-small">
14    <p>
15      <markdown ngPreserveWhitespaces>
16        {{ data.article.content }}
17      </markdown>
18    </p>
19    <p></p>
20  </div>
21</div>

• Open your app.modules.ts file, import your component, add it to the declarations array and add another route for this component:

1...
2import { ArticleComponent } from "./article/article.component";
3...
4
5const appRoutes: Routes = [
6  { path: "", component: ArticlesComponent },
7  { path: "article/:id", component: ArticleComponent },
8];
9...
10
11declarations: [
12  AppComponent,
13  NavComponent,
14  ArticlesComponent,
15  ArticleComponent
16],
17...

• Click on any article!

Awesome you can now visit any article!

Category component

With this component, you'll be able to fetch articles depending on the selected category you are visiting.

• Create a category component by running the following command:

  ng generate c category --skip-import

• Create a app/apollo/queries/category/articles.js file containing the following:

1import gql from "graphql-tag";
2
3const CATEGORY_ARTICLES_QUERY = gql`
4  query Category($id: ID!) {
5    category(id: $id) {
6      id
7      name
8      articles {
9        id
10        title
11        content
12        image {
13          url
14        }
15        category {
16          id
17          name
18        }
19      }
20    }
21  }
22`;
23
24export default CATEGORY_ARTICLES_QUERY;

• Open your category/category.component.ts file and paste the following code:

1import { Component, OnInit } from "@angular/core";
2import { Apollo } from "apollo-angular";
3import gql from "graphql-tag";
4import CATEGORY_ARTICLES_QUERY from "../apollo/queries/category/articles";
5import { ActivatedRoute, ParamMap } from "@angular/router";
6import { Subscription } from "rxjs";
7
8@Component({
9  selector: "app-category",
10  templateUrl: "./category.component.html",
11  styleUrls: ["./category.component.css"]
12})
13export class CategoryComponent implements OnInit {
14  data: any = {};
15  category: any = {};
16  loading = true;
17  errors: any;
18  leftArticlesCount: any;
19  leftArticles: any[];
20  rightArticles: any[];
21  id: any;
22
23  private queryCategoriesArticles: Subscription;
24
25  constructor(private apollo: Apollo, private route: ActivatedRoute) {}
26
27  ngOnInit() {
28    this.route.paramMap.subscribe((params: ParamMap) => {
29      this.id = params.get("id");
30      this.queryCategoriesArticles = this.apollo
31        .watchQuery({
32          query: CATEGORY_ARTICLES_QUERY,
33          variables: {
34            id: this.id
35          }
36        })
37        .valueChanges.subscribe(result => {
38          this.data = result.data
39          this.category = this.data.category.name
40          console.log(this.data)
41          this.leftArticlesCount = Math.ceil(this.data.category.articles.length / 5);
42          this.leftArticles = this.data.category.articles.slice(0, this.leftArticlesCount);
43          this.rightArticles = this.data.category.articles.slice(
44            this.leftArticlesCount,
45            this.data.category.articles.length
46          );
47          this.loading = result.loading;
48          this.errors = result.errors;
49        });
50    });
51  }
52  ngOnDestroy() {
53    this.queryCategoriesArticles.unsubscribe();
54  }
55}

Here you are doing the same thing that you did in your ArticlesComponent, but you are fetching articles depending on the selected category.

• Open your category/category.component.html file and paste the following code:

1<div class="uk-section">
2  <div class="uk-container uk-container-large">
3    <h1>{{ category }}</h1>
4
5    <div class="uk-child-width-1-2" uk-grid>
6      <div>
7        <a
8          routerLink="/article/{{ article.id }}"
9          routerLinkActive="active"
10          *ngFor="let article of leftArticles"
11          class="uk-link-reset"
12        >
13          <div class="uk-card uk-card-muted">
14            <div *ngIf="article.image" class="uk-card-media-top">
15              <img
16                src="http://localhost:1337{{ article.image.url }}"
17                alt=""
18                height="100"
19              />
20            </div>
21            <div class="uk-card-body">
22              <p
23                id="category"
24                *ngIf="article.category"
25                class="uk-text-uppercase"
26              >
27                {{ article.category.name }}
28              </p>
29              <p id="title" class="uk-text-large">{{ article.title }}</p>
30            </div>
31          </div>
32        </a>
33      </div>
34      <div>
35        <div class="uk-child-width-1-2@m uk-grid-match" uk-grid>
36          <a
37            routerLink="/article/{{ article.id }}"
38            routerLinkActive="active"
39            *ngFor="let article of rightArticles"
40            class="uk-link-reset"
41          >
42            <div class="uk-card uk-card-muted">
43              <div *ngIf="article.image" class="uk-card-media-top">
44                <img
45                  src="http://localhost:1337{{ article.image.url }}"
46                  alt=""
47                  height="100"
48                />
49              </div>
50              <div class="uk-card-body">
51                <p
52                  id="category"
53                  *ngIf="article.category"
54                  class="uk-text-uppercase"
55                >
56                  {{ article.category.name }}
57                </p>
58                <p id="title" class="uk-text-large">{{ article.title }}</p>
59              </div>
60            </div>
61          </a>
62        </div>
63      </div>
64    </div>
65  </div>
66</div>

• Open your app.modules.ts file, import your component, add it to the declarations array and add another route for this component:

1...
2import { CategoryComponent } from "./category/category.component";
3...
4
5const appRoutes: Routes = [
6  { path: "", component: ArticlesComponent },
7  { path: "article/:id", component: ArticleComponent },
8  { path: "category/:id", component: CategoryComponent }
9];
10...
11
12declarations: [
13  AppComponent,
14  ArticlesComponent,
15  ArticleComponent,
16  NavComponent,
17  CategoryComponent
18],
19
20...

Awesome! You can now navigate through categories :)

Conclusion

Huge congrats, you successfully achieved this tutorial. I hope you enjoyed it!

Still hungry?

Feel free to add additional features, adapt this project to your own needs, and give your feedback in the comments section.

If you want to deploy your application, check our deployment documentation.

Write for the community

Contribute and collaborate on educational content for the Strapi Community.

Can't wait to see your contribution!

Please note: Since we initially published this blog post, we released new versions of Strapi and tutorials may be outdated. Sorry for the inconvenience if it's the case. Please help us by reporting it here.

Get started with Strapi by creating a project using a starter or trying our live demo. Also, consult our forum if you have any questions. We will be there to help you.
